DESCRIPTION

This replacement is compatible with UNIVERSAL Air Conditioners.

Ricambi Appliance Spares is a family-owned business based in Sydney, NSW, with strong industry roots. We specialize in sourcing genuine, OEM, and high-quality appliance parts from around the world, including compressors, to serve the Australian market. Our expertise focuses on Italian and German brands, along with a wide range of compressors from global manufacturers.

TECHNICAL SPECS

Title: CM520 PORTERBLE LIFTER

MPN: CM520

SKU Number: HTN_0001023

Notes:

Overview

The CM520 portable lifter has the maximum lift height in the portable lifter range - being able to lift loads up to 4.9 meters.

The CM520 is a larger lifter than the CM340 and comes with wheels.

As with the CM340, the CM520 comes with a telescoping mast. Both models are operated with a variable speed trigger switch allowing fine positiong of the load in order to align with mounting brackets etc.

The 4 adjustable legs, enable the CM520 to operate on eneven surfaces. One leg can be also be configured in a "squat" configuration to allow operation adjactent to walls.

It is Ideally suited for the Air Conditiong and HVAC industry - both for installations and maintenance.

Key Features

  • Constructed with heat treated, robust aluminum - compact, safe and reliable.
  • Telescoping mast
  • No tools required to setup the lift - simply undfold, setup and operated within 60 seconds.
  • Single Person setup.
  • 4 Legs stabilise the lifter. Each leg has variable, independant adjustment for uneven ground - such as stairways. One leg is indepenant so you can operate adjacent to a wall.
  • Controller with variable speed switch.
  • Variable speed controller enables soft start with fine adjustment for operating height.
  • Emergency Stop Button.
  • Manual override: In case of power failure or sites with no power operate manually with supplied handle or cordless drill and 17mm socket.
  • Automatic Overload clutch: Prevents apprentices overloading the lifter.
  • Level included - Assists alinging the mast vertically with the adjustable legs.
  • Platform standard - for air conditioners, awnings, garage doors etc. Optional extesion arms available.
  • Highly Portable, the compact design folds, making it easy for one person to carry the lifter to/from job.
  • Easily transported in van, car or utility.

Compact and easily transported

The CM520 is easily moved on-site with the use of the transport wheels as shown.

Integrated Level

Integrated level on the mast helps ensure the mast is vertical before operation.

Adjust the legs independantly for uneven surfaces to make sure the mast is vertical!

Up/Down Controller

Controller:

  • Easy pistol-grip hold
  • Variable speed trigger - exact height positioning with precise control of speed
  • Belt clip for convenience
  • Up/Down level
  • Robust casing

Emergency Stop

Emergency Stop:

  • Safety
  • Switches to manual control

Manual Override

Switch to manual operation at locations without power or in case of a power failure.

  • Use the included handle as shown
  • OR - use a cordless drill with a 17mm socket
  • Engage the Emergency Stop to switch to manual control!

Remove the Handle to manually operate the lifter when now power is not available. OR Use a cordless drill with a 17mm socket

Industry Sectors

  • Air Conditioning installation/removal.
  • Glass handling - ideal for housing and construction such as shopping centre glass curtains.
  • Solar Systems
  • Garage door installation/removal.
  • Anwning installation/removal.
  • Plasterboard

Optional Adapters
The portable lifter range (CM340, CM520 and CA400) have optional-interchangeable adapters.

OptionalAdapter/Compatable with CM340
Extension Arms/Garage Doors; Awnings and Building
GL4V/Glass; Solar Panels; Sheet Metal; Train/Railways galss installation
Plaster Cradle/Plasterboard and Other sheeting

Accessories Optional

CM Extensions Arm / $325.00

Castor Set for CM340 / $300.00

CM Platform / $900.00

DW Plasterboard Cradle / $1,500.00


Ricambi Appliance Spares is not liable for any damage resulting from incorrect selection or improper installation of spare parts.

All electrical components must be installed by a qualified electrician, and all technical products should be installed by a professional technician.

PCB returns will not be accepted once theseal is broken.

Errors and Omissions Disclaimer:

While we strive to ensure all information on this website is accurate and genuine, Ricambi accepts no responsibility for its use or for any potential infringements of patents or third-party rights that may occur.

Legal Disclaimer:

All trademarks, logos, and other representations are the property of their respective owners. The use of brand names, trademarks, or logos does not implythat RICAMBI is affiliated with or authorized by those brands, companies, or trademark holders.

RICAMBI does not claim ownership of any products or services provided by these companies.

SPECIFICATIONS
SKU HTN_0001023
Brand Universal
