DESCRIPTION

This replacement is compatible with EMBRACO Air Conditioners.

Ricambi Appliance Spares is a family-owned business based in Sydney, NSW, with strong industry roots. We specialize in sourcing genuine, OEM, and high-quality appliance parts from around the world, including compressors, to serve the Australian market. Our expertise focuses on Italian and German brands, along with a wide range of compressors from global manufacturers.

TECHNICAL SPECS

Title: EMT6170Z(MBP) Embraco Compressor R134a MH TEMP Disp. 7.7cc Cool cap 806W @-5.deg

Brand: Embraco

MPN: R0050003

SKU Number: HTN_0001562

Notes:

EMT6170Z(MBP) Embraco Compressor R134a MH TEMP Disp. 7.7cc Cool cap 806W @-5.de

Specification

Embraco Aspera Freezer/Refrigerator Compressor :

Low levels of noise and vibration

Standard, medium, high and very high levels of efficiency

Available for R-134a, R-600a and R-290

Developed for LBP applications can be adapted for M / HBP applications

Designed for domestic and medium-sized commercial applications.

Description:

Refrigerant:R-134aDisplacement (cc):7.69
Voltage:200-220 V 50 Hz / 230 V 60 Hz 1 ~Lubricant Type:ISO22
Frequency (Hz):50Lubricant Charge (ml):350
Application:LBPMotor Type:RSIR
HP:1/4Starting Torque:LST
Efficiency:1,10Type of Test:ASHRAE32
Capacity:217

External Features:

ShapeMaterialDiameter (mm)
Suction ConnectorSlanted 42°Copper8,10
Discharge ConnectorStraightCopper6,10
Process ConnectorSlanted 42°Copper6,10
Oil Cooler:
Base Plate:European Standard
Tray Holder:No
Weight (kg):10,95

Application

Maximum ambient temperature (?C):43
Expansion device:Capillary
Cooling:Fan Cooling
Air flow rate:

Mechanical Data

Bill of materials:262AK50
Starting torque:Low Starting Torque
Bore (mm):24,28
Stroke (mm):10,00
Weight (kg):10,95

Electrical Data

Motor type:RSIR
Winding Resistance (25?C) - Start:29,92
Winding Resistance (25?C) - Run:5,96
