DESCRIPTION

This replacement is compatible with MASTERCOOL Air Conditioners.

Ricambi Appliance Spares is a family-owned business based in Sydney, NSW, with strong industry roots. We specialize in sourcing genuine, OEM, and high-quality appliance parts from around the world, including compressors, to serve the Australian market. Our expertise focuses on Italian and German brands, along with a wide range of compressors from global manufacturers.

TECHNICAL SPECS

Title: MASTERCOOL 6CFM VACUUM PUMP R32 (TWO STAGE) 220V 142Litre (90066-220-BSF)

Brand: Mastercool

MPN: MC90066-220-BSF

SKU Number: HTN_0002389

Notes:

MASTERCOOL 6CFM Spark Free VACUUM PUMP  R32 (TWO STAGE) 220V 142Litre Model: 90066-220-BSF

Product Description

APPROVED FOR ALL AIR CONDITIONING REFRIGERANTS INCLUDING A2L AND A3 FLAMMABLE REFRIGERANTS

A good quality vacuum pump is an integral tool for complete A/C service. Mastercool vacuum pumps are durable and time tested. They stand up to the most grueling conditions and will provide years of reliable service. Mastercool offers a complete selection of pumps. Regardless of your service requirements, Mastercool has a model for your applications.

  • Constructed with Spark Free Components
  • New U.S. Design
  • Stronger Motor
  • Gas Ballast Valve Helps Prevent Oil Contamination Caused by High Moisture
  • Easily Removable Vapor Discharge/Oil Fill Port. Contains Internal Check Valve to Prevent Escape of Liquid Oil
  • Large Oil Level Sight Glass with Max/Min Oil Level Indicator
  • Easily Accessible  Oil Drain Valve
  • Large, Light Weight Reinforced Base for Stable Positioning
  • Field Replaceable Cartridge
  • Cooling Fins to Keep Temperature Cooler During Extended Motor Operation
  • High Volume Fan Provides Cool Air to Motor and Pump
  • Manifold Valve Isolates Pump from the System when Testing for Leaks. Includes 3 Inlet Ports, 1/4”, 3/8” SAE and 1/2” ACME
  • Dual Voltage Capability
  • Thermally Protected Motor  with On/Off Rocker Switch

SPECIFICATIONS:

  • No. of Stages: 2
  • Free Air Displacement: 170 lit/min / 142 lit/min
  • Ultimate Vacuum: 15 Microns
  • Pump Motor: 1/2 HP
  • Pump Speed: 1440 RPM
  • Electrical Specs: 220 V / 50/60 Hz
  • Power Cord: 220 V Cable (Shuko)
  • Shipping Weight: 24.25 lbs (11 kg)
  • Dimensions in cm: 37.9 x 16.7 x 27.5

* PLEASE NOTE: The micron readings on all vacuum pumps represent optimal laboratory conditions. Field conditions may vary from these readings.

SERVICE INFORMATION:
Oil Capacity: 15 oz / 440 ml

AVAILABLE DOWNLOADS

Flier
