DESCRIPTION

This replacement is compatible with UNIVERSAL Air Conditioners.

Ricambi Appliance Spares is a family-owned business based in Sydney, NSW, with strong industry roots. We specialize in sourcing genuine, OEM, and high-quality appliance parts from around the world, including compressors, to serve the Australian market. Our expertise focuses on Italian and German brands, along with a wide range of compressors from global manufacturers.

TECHNICAL SPECS

Title: RCU315 12.5" 240V 999L/S 1420rpm Weatherproof Kitchen Vertical Exhaust Roof Fan

MPN: RCU315

SKU Number: HTN_0000125

Notes:

Weatherproof Kitchen Vertical Exhaust Mushroom Roof Fan
Model: RDU315(4P)
  • Impeller Dia: 12.5 inch or 315mm
  • Power: 250w
  • Voltage: 220V 50Hz
  • Air Flow: 999l/s
  • Fan Speed: 1420RPM
  • Noise: 62dB
  • Motor Rated Current Amps: 1.4

Rcu Series: The Product Is Made In Aluminum Alloy, Which Is Cutting, By Laser To Ensure High-precision Mold Line. The Base Is Aluminum Alloy For One-time Stretch. Driven Cavity Cover Adopt Galvanized Material,Which Can Open With Hands, And Convenient To Daily Cleaning Maintenance. Different Ways Of Motor With Different Transmission Need To Select Different Motor Bracket. The Impeller Adopts Laser Cutting Technology and Die Stretch Forming. A Different Work Environment Needs To Adopt Different Impeller Material. Carbon Steel, Stainless Steel And Aluminum Alloy Impeller Are Optional. The Surface Of The Impeller Adopts Industrial Spraying. Impeller Balance Test Grades Are In Strict Accordance With The G4.0 ISO1940, And Meet Its Requirements. In This Series, Roof Blower Use Aluminum Alloy Wheel.

Impeller Dia
Model(Inch)(mm)Power(w)VoltageAir Flow(L/S)Fan Speed  (RPM)
RDU-A-315HBS-A-N-AL12.5inch315250240V 50Hz9991420
RDU-B-400HBS-A-N-AL16inch400750240V 50Hz18881400
16inch400750415V  50Hz18881400
RDU-B-450HBS-A-N-AL18inch4501100240V 50Hz27001400
18inch4501100415V  50Hz27771400
RDU-B-315HBS-A-N-AL20inch5001100415V 50HZ2777960


Ricambi Appliance Spares is not liable for any damage resulting from incorrect selection or improper installation of spare parts.

All electrical components must be installed by a qualified electrician, and all technical products should be installed by a professional technician.

PCB returns will not be accepted once theseal is broken.

Errors and Omissions Disclaimer:

While we strive to ensure all information on this website is accurate and genuine, Ricambi accepts no responsibility for its use or for any potential infringements of patents or third-party rights that may occur.

Legal Disclaimer:

All trademarks, logos, and other representations are the property of their respective owners. The use of brand names, trademarks, or logos does not implythat RICAMBI is affiliated with or authorized by those brands, companies, or trademark holders.

RICAMBI does not claim ownership of any products or services provided by these companies.

SPECIFICATIONS

SKU HTN_0000125
Brand Universal
Shipping Weight 1.0000kg
