DESCRIPTION

This replacement is compatible with UNIVERSAL Air Conditioners.

Ricambi Appliance Spares is a family-owned business based in Sydney, NSW, with strong industry roots. We specialize in sourcing genuine, OEM, and high-quality appliance parts from around the world, including compressors, to serve the Australian market. Our expertise focuses on Italian and German brands, along with a wide range of compressors from global manufacturers.

TECHNICAL SPECS

Title: SF-105 TEMPERATURE CONTROLLER

MPN: SF-105

SKU Number: HTN_0003150

Notes:

Brand: SHANGFANG

Model: sf-134

Specifications

1. Termostat control
2. Double sensors
3. For fan cooling&low temperature control
4. Range: -45 to 45 oC

   Digital Termostat  SF-105

 Features

1 For air cooling of low temperature

2 Double sensors

3 Temperature control

4 Evap.Fan control

5 Automatic/Manual defrost by electric heater/hot gas

6 High/Low temperature alarm

7 Time/Temp.setting to end defrost

8 Re-start delay

9 Celsius/Fahrenheit degrees

10 Mini-sized and integrated intelligent controller

11 Applicable to the compressor of 1HP



Technical Data

1 Range of temperature displalyed:-45°C~45°C(-40°F~120°F)

2 Range of set temperature:-45°C~45°C(-40°F~120°F)

3 Accuracy:±1°C(± 2°F)

4 Compressor:NO.20A/250VAC

5 Defrost:NO.10A/250VAC

6 Evap.Fan:NO.5A/250VAC

7 Output of the outside sealed transformer:12VAC

8 Temperature sensor:NTC,2pcs(for cold room temp.&defrost control),2m(L)

9 Temperature of the operating environment:-10°C~60°C

    Relative humidity:20%~90%(Non-condensing)

10 Dimension:77(L)x35(W)x60(D)mm

11 Mounting hole dimension:71(L)x29(W)mm



 Circuit diagram


Ricambi Appliance Spares is not liable for any damage resulting from incorrect selection or improper installation of spare parts.

All electrical components must be installed by a qualified electrician, and all technical products should be installed by a professional technician.

PCB returns will not be accepted once theseal is broken.

Errors and Omissions Disclaimer:

While we strive to ensure all information on this website is accurate and genuine, Ricambi accepts no responsibility for its use or for any potential infringements of patents or third-party rights that may occur.

Legal Disclaimer:

All trademarks, logos, and other representations are the property of their respective owners. The use of brand names, trademarks, or logos does not implythat RICAMBI is affiliated with or authorized by those brands, companies, or trademark holders.

RICAMBI does not claim ownership of any products or services provided by these companies.

SPECIFICATIONS

SKU HTN_0003150
Brand Universal
Shipping Weight 1.0000kg
